Nocpix Compact Thermal Monocular 384x288 19 mm
Nocpix Compact Thermal Monocular 384x288 19 mm
Couldn't load pickup availability
LUMI brings the power of thermal observation devices to a compact and user-friendly form-factor for hunters on-the-go. The all-new LUMI series of handheld thermal monoculars features a high quality thermal sensor available in 384x288 (L35 L19) or 640x512 (H35) paired with a 1024x768 AMOLED display. Available models offer either a 2.5x base magnification (H35) for a wider field of view or a 4x base magnification (L35) for identifying targets at greater distances.
Nocpix's advanced Reality+ image processing algorithm and a ≤18 mK NETD (thermal sensitivity) rating provide sharp high-contrast images. Powering the LUMI is simple and affordable using common interchangeable 18650 style batteries. As a powerful tool for scouting and scanning LUMI was designed to be as compact and ergonomic as possible while still offering impressive image detail and clarity; LUMI weighs 12 ounces and easily fits in the palm of the hand a pocket or the included MOLLE-compatible case.
- Lightweight and compact design easily fits in a pocket or the include MOLLE-compatible pouch.
- Weatherproof rubberized texture increases durability and is not cold to the touch.
- Powered by a common 18650 style rechargeable battery with a spare battery included.
- Advanced R+ image processing enhances image quality during digital zoom.
- Onboard photo video and audio recording.
- Comfortable ambidextrous vertical design.
Share
Specifications
Specifications
| Manufacturer | IRay USA |
|---|---|
| Battery Count | 2 |
| Battery Type | 18650 Rechargeable |
| Brand | Nocpix |
| CA Prop 65 | Yes |
| Color | Black |
| Condition | New |
| Optics Length | 5.5" |
| Optics Type | Thermal Monocular |
| Thermal Digital Zoom | 4x |
| Thermal Diopter Adj | -5/+5 |
| Thermal Display / Monitor Type | AMOLED |
| Thermal Display Resolution | 1024 x 768 |
| Thermal Eye Relief | 25mm |
| Thermal FOV Deg | 13.8° × 10.4° (H × V) |
| Thermal Human Detect Range | 1070 yds |
| Thermal Imaging Palettes | White Black Red Hot Color Violet Crimson Viridian |
| Thermal Magnification | 2x |
| Thermal NETD | <18mK |
| Thermal Objective Lens (Focal Length) | 19mm F/0.9 |
| Thermal Operating Temperature | -4°F~122°F |
| Thermal PIP Mode | Yes |
| Thermal Sensor Frame (Refresh) Rate | 50 Hz |
| Thermal Sensor Pixel Interval | 12 um |
| Thermal Sensor Resolution | 384 x 288 |
| Thermal Storage | 32 GB |
| Warranty | Mfg 5 Year |
| Waterproof | IP67 |
| Weight | 11.82 oz |
