ATN BlazeTrek 619 Thermal Monocular 12 Micron
ATN BlazeTrek 619 Thermal Monocular 12 Micron
Couldn't load pickup availability
The ATN BlazeTrek 619 Thermal Monocular features an advanced thermal sensor that offers resolutions of 384x288 and 640x512 (50 Hz) with a 12 μm pixel size and an exceptional NETD rating of <25mK enhancing sensitivity to temperature variations for improved image clarity.
Select from five color palettes to customize your viewing experience: White Hot Black Hot Rainbow Iron Red and Alarm.
Offers integrated features for capturing still images and recording video videos and pictures can be stored on the device's internal memory of 32Gb.
Connect the monocular wirelessly to your smartphone and app to adjust settings capture photos or record thermal videos directly from your phone.
Easily fits in a pocket for convenient portability allowing you to take it anywhere you go.
Adjust the monocular for different users using the diopter adjustment wheel ensuring a clear and sharp image for each viewer.
Built-in rechargeable battery with up to 9 hours of operation time and external power supply option.
Share
Specifications
Specifications
| Manufacturer | American Technologies Network |
|---|---|
| Battery Count | 1 |
| Battery Run Time | 7 hr |
| Battery Type | Rechargeable |
| Brand | ATN |
| Brand Family | Blaze Trek |
| CA Prop 65 | Yes |
| Color | Black |
| Condition | New |
| Country of Origin | USA |
| Material | Aluminum |
| Optics App Support | ATN Blaze App |
| Optics Class | Thermal Imaging |
| Optics Finish | Anodized |
| Optics Length | 6.2" |
| Optics Mounting System | Not Included |
| Optics Objective | 19 |
| Optics Shockproof | Yes |
| Optics Type | Thermal Handheld Monocular |
| Thermal Bluetooth | Yes |
| Thermal Core | ATN Obsidian Core LT |
| Thermal Detector Type | 12um Uncooled 50 Hz |
| Thermal Diopter Adj | Yes |
| Thermal Display / Monitor Type | LCOS |
| Thermal Display Resolution | 800 x 600 |
| Thermal Eye Relief | 15mm |
| Thermal FOV Deg | 22.8° x 18.3° |
| Thermal Human Detect Range | 990 yds |
| Thermal Human ID Range | 100 |
| Thermal Human Recog Range | 200 |
| Thermal Imaging Palettes | White Black & Green Hot / Iron Red / Alarm / Sepia |
| Thermal Magnification | 2.7-21x |
| Thermal NETD | <25 mk |
| Thermal Operating Temperature | -30°C to +55°C (-22°F to +131°F) |
| Thermal Optics Wi-Fi | Yes |
| Thermal PIP Mode | Yes |
| Thermal Power Supply | Charging USB Type C |
| Thermal Recording Type | On-Board Video and Still Images |
| Thermal Sensor Frame (Refresh) Rate | 50 Hz |
| Thermal Sensor Pixel Interval | 12 um |
| Thermal Sensor Resolution | 640 x 512 |
| Thermal Snapshot Capture | Yes |
| Thermal Standby Mode | Yes |
| Thermal Storage | 32 GB |
| Warranty | Mfg 3 Year Limited |
| Waterproof | IP67 |
| Weight | 11.2 oz |
